Industrial Flanges

Sailesh Metal Corporation manufactures and supplies industrial flanges for piping, pressure, process and fabrication applications across India and overseas markets. Our flanges are supplied in a wide selection of material grades, sizes, pressure classes and facing options to suit the requirements of refineries, chemical plants, pharmaceutical units, power projects, marine applications, water systems, general engineering and infrastructure projects.

With experience in metals since 1975, Sailesh Metal Corporation focuses on reliable material selection, dimensional accuracy and practical supply support for buyers who need standard as well as project-specific flange requirements. Flanges can be supplied as per internationally accepted standards or custom drawings, based on application, pressure rating, temperature condition and pipe specification.

Quick Overview

Requirement	Available Range / Details
Product Types	Weld Neck, Long Weld Neck, Slip-On, Socket Weld, Threaded, Blind, Lap Joint and Plate Flanges
Material Categories	Stainless Steel, High Nickel Alloys, Carbon Steel, Low-Temperature Carbon Steel, Alloy Steel and Mild Steel
Size Range	1/2 in NB to 48 in NB, subject to type, grade and order requirement
Pressure Classes	Class 150, 300, 600, 900, 1500 and 2500; PN6 to PN40; API or project-specific pressure ratings on request
Face Types	Flat Face (FF), Raised Face (RF) and Ring Type Joint (RTJ)
Standards	ASME/ANSI B16.5, ASME/ANSI B16.47 Series A and B, MSS SP-44, API-605, AWWA, BS, JIS and custom engineering drawings
Customisation	Available as per drawings, material grade, bore requirement, face finish, drilling pattern and project specification

Material Grades Manufactured / Supplied

The following material categories and grades can be supplied based on customer requirement, applicable standard, size and quantity. Buyers are requested to share the required grade, standard and application details at the enquiry stage for accurate selection and quotation.

Material Category	Common Grades / Specifications
Stainless Steel	ASTM A182 / ASTM A479: 304, 304L, 304H, 316, 316L, 316H, 316Ti, 309, 310, 317L, 321, 347, 904L, 17-4PH, SMO 254 and 400 Series grades
High Nickel Alloys	Hastelloy, Nickel, Monel, Inconel, Incoloy, Alloy 20 and Cupro Nickel. Common applicable specifications include ASTM B564, B335, B649, B462 and B151, depending on grade and product form.
Carbon Steel & Low-Temperature Steel	ASTM A105 and ASTM A350 LF2
Alloy Steel	ASTM A182 F5, F9, F11, F12, F21, F22 and F91
Mild Steel	1008, 1010, 1015, 1020, CK35, CK45, CK55, CK60 and equivalent grades, as per requirement

Technical Specifications

Parameter	Specification / Buyer Guidance
Dimensional Standards	ASME/ANSI B16.5, ASME/ANSI B16.47 Series A and B, MSS SP-44, ASA, API-605, AWWA and custom drawings
Nominal Size Range	1/2 in NB (15 NB) to 48 in NB (1200 NB), subject to flange type and grade
Pressure Class	150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS and 2500 LBS
British / European Options	BS 4504, BS 1560, BS 10; PN6, PN10, PN16, PN25 and PN40
BS Table Options	Table D, E, F, H, J and K, where applicable
API / Project Ratings	PSI 2000, 3000, 5000, 10000 and other project-specific ratings on request
JIS Options	JIS B2220; 5K, 10K, 16K and other applicable ratings
Flange Facing	FF – Flat Face, RF – Raised Face, RTJ – Ring Type Joint
Manufacturing / Supply Basis	Standard flange dimensions, project drawings, customer drawings or application-specific requirements
Documents	Material Test Certificate, test reports and inspection documentation can be provided as per order terms and material availability

Types of Industrial Flanges

Weld Neck Flanges

Weld neck flanges are used where strong welded joints and reliable pressure handling are important. The long tapered hub helps transfer stress from the flange to the pipe, making this type suitable for high-pressure, high-temperature and critical piping lines. The bore of the flange is matched with the pipe bore to support smoother flow and reduce turbulence at the joint.

Common use: Refineries, chemical plants, oil and gas lines, power plants, high-pressure process piping and systems where long-term joint strength is important.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Slip-On Flanges

Slip-on flanges are designed with a bore that allows the flange to slide over the pipe before welding. They are generally welded on both the inside and outside of the flange, making them easier to align and install than weld neck flanges in many fabricated piping systems. They are often selected when cost efficiency and ease of installation are important.

Common use: Low to medium pressure piping, fabrication work, water lines, general engineering, agricultural systems, textile units, pharmaceutical support systems and chemical handling applications.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Blind Flanges

Blind flanges are solid flanges used to close the end of a pipe, valve, pressure vessel opening or piping system. They are useful where a line needs to be sealed, isolated or kept ready for future expansion. Since they can be bolted and removed, they also provide access for inspection, cleaning or modification of a piping system.

Common use: Line isolation, pressure testing, terminal pipe ends, valve manifolds, pressure vessel openings and future expansion points.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Socket Weld Flanges

Socket weld flanges are used by inserting the pipe into a recessed socket area and then welding around the outside. They are commonly selected for small-bore piping and high-pressure lines where a neat internal flow path and strong welded connection are required. Material selection is important for corrosive or high-temperature service conditions.

Common use: Small diameter high-pressure piping, steam lines, hydraulic lines, process plants, LNG-related systems, marine lines and mining applications.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Threaded Flanges

Threaded flanges have internal threads that allow them to be connected to externally threaded pipes without welding. They are useful in applications where welding is not preferred or where site conditions make hot work difficult. They are generally used for smaller sizes and lower pressure applications, subject to engineering approval.

Common use: Utility lines, low-pressure piping, temporary connections, hazardous areas where welding may not be suitable and maintenance-friendly piping systems.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Lap Joint Flanges

Lap joint flanges are used together with stub ends. The stub end is welded to the pipe, while the flange remains free to rotate behind it. This makes alignment easier during assembly and allows the flange to be reused in certain systems. Since the flange itself does not directly contact the fluid, it can be useful in systems where corrosion resistance is required through the wetted component.

Common use: Systems requiring frequent dismantling, inspection, cleaning, alignment flexibility or cost-effective use of alloy wetted parts.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Plate Flanges

Plate flanges are flat, economical flange components produced for applications where a forged hub is not required. They are often used in low-pressure lines, water distribution, irrigation, fabrication and general utility systems. Plate flanges are selected for practical installation, lower cost and standardised bolting connection requirements.

Common use: Water pipelines, irrigation, fabrication, municipal systems, low-pressure industrial lines and general engineering projects.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Long Weld Neck Flanges

Long weld neck flanges have an extended neck or barrel-shaped hub and are generally used where the flange itself becomes part of a nozzle or pressure vessel connection. They provide added reinforcement and are used in specialised pressure and temperature applications where a standard weld neck flange may not be the ideal fit.

Common use: Pressure vessels, heavy-duty process systems, petroleum applications, chemical processing and high-temperature service conditions.

Specification	Available Range
Size Range	1/2 in NB to 48 in NB, subject to type, material grade and order requirement
Pressure Class	Class 150 to Class 2500; PN6 to PN40; API/project pressure ratings on request
Face Types	FF, RF and RTJ, subject to flange type and standard
Manufacturing / Supply Basis	Standard dimensions or custom drawings, as per project requirement

Industries & Applications Served
Sailesh Metal Corporation supplies industrial flanges for a wide range of process, pressure and utility applications. Typical industries include:
- Oil refineries, fuel storage and petrochemical plants
- Chemical processing and fertiliser units
- Pharmaceutical and sanitary process support systems
- Power generation and energy infrastructure
- Shipbuilding, marine and offshore structures
- Water treatment, wastewater, municipal and utility pipelines
- Paper mills and industrial process plants
- Large-scale infrastructure, fabrication and turnkey projects
- Agricultural, irrigation and general engineering applications
Why Choose Sailesh Metal Corporation
- Established metal industry experience since 1975
- Wide range of ferrous, non-ferrous and specialty alloy material options
- Industrial flange supply across standard and project-specific requirements
- Support for custom drawings, pressure classes and application-based specifications
- Mumbai-based supply support with experience across industrial buyers and project requirements
- Capability to support large-volume requirements, with over 4000 tons of steel manufactured annually as stated by the company

How to Send an Enquiry
To help our team quote accurately, please share the following details when enquiring for industrial flanges:
- Flange type: Weld Neck, Slip-On, Blind, Socket Weld, Threaded, Lap Joint, Plate or Long Weld Neck
- Size / NB and pipe schedule or bore requirement
- Material grade and applicable standard
- Pressure class or PN/API rating
- Face type: FF, RF or RTJ
- Quantity required
- Drawing, if the requirement is non-standard or project-specific
- Application details such as fluid, pressure, temperature and industry, if available
Frequently Asked Questions
1. What types of industrial flanges do you supply?
2. We supply weld neck, long weld neck, slip-on, socket weld, threaded, blind, lap joint and plate flanges. Availability depends on size, material grade, pressure class and order requirement.
3. Which materials are available for flanges?
4. Flanges can be supplied in stainless steel, high nickel alloys, carbon steel, low-temperature carbon steel, alloy steel and mild steel. Common grades include 304, 316, 904L, SMO 254, Hastelloy, Monel, Inconel, ASTM A105, ASTM A350 LF2 and ASTM A182 alloy steel grades.
5. What standards do your flanges follow?
6. Flanges can be supplied as per ASME/ANSI B16.5, ASME/ANSI B16.47, MSS SP-44, API-605, AWWA, BS, JIS and customer drawings, based on project requirement.
7. What pressure classes are available?
8. Common pressure classes include 150, 300, 600, 900, 1500 and 2500. PN6 to PN40 and API/project-specific ratings can also be considered based on the application.
9. Can you supply custom flanges as per drawing?
10. Yes. Custom flanges can be supplied as per approved drawings, material grade, drilling pattern, bore, face finish and dimensional requirements.
11. How should I choose the correct flange?
12. The correct flange depends on pipe size, material grade, pressure class, temperature, fluid type, corrosion requirement, installation method and applicable project standard. Share your technical requirement with our team for suitable guidance.

Share your flange requirement with our team for grade selection, availability and pricing support.
